For senior or graduate-level students taking a first course in Control Theory (in departments of Mechanical, Electrical, Aerospace, and Chemical Engineering). A comprehensive, senior-level textbook for control engineering. Ogatas Modern Control Engineering, 5/e, offers the comprehensive coverage of continuous-time control systems that all senior students must have, including frequency response approach, root-locus approach, and state-space approach to analysis and design of control systems. The text provides a gradual development of control theory, shows how to solve all computational problems with MATLAB, and avoids highly mathematical arguments. A wealth of examples and worked problems are featured throughout the text. The new edition includes improved coverage of Root-Locus Analysis (Chapter 6) and Frequency-Response Analysis (Chapter 8). The author has also updated and revised many of the worked examples and end-of-chapter problems. This text is ideal for control systems engineers.
Contents Preface Chapter 1 Introduction to Control Systems 1-1 Introduction 1-2 Examples of Control Systems 1-3 Closed-Loop Control versus Open-Loop Control 1-4 Outline of the Book Chapter 2 Mathematical Modeling of Control Systems 2-1 Introduction 2-2 Transfer Function and impulse Response Function 2-3 Atomatic Control Systems 2-4 Modeling in state space 2-5 State-Space Representation of Scalar Differential Equation System 2-6 Transformation of Mathematical models with MATLAB 2-7 Linearization of Nonlinear Mathematical Models Example Problems and Solutions Problems Chapter 3 Mathematical Modeling of Mechanical Systems and Electrical Systems 3-1 Introduction 3-2 Mathematical Modeling of Mechanical Systems 3-3 Mathematical Modeling of Electrical Systems Example Problems and Solutions Problems Chapter 4 Mathematical Modeling of Fluid Systems and Thermal Systems 4-1 Introduction 152 4-2 Liquid-Level Systems 4-3 Pneumatic Systems 4-4 Hydraulic Systems 4-5 Thermal Systems Example Problems and Solutions Problems Chapter 5 Transient and Steady-State Response Analyses 5-1 Introduction 5-2 First-Order Systems 5-3 Second-Order Systems 5-4 Higher Order Systems 5-5 Transient-Response Analysis with MATLAB 5-6 Rouths Stability Criterion 5-7 Effects of Integral and Derivative Control Actions on System Performance 5-8 Steady-State Errors in Unity-Feedback Control Systems Example Problems and Solutions Problems Chapter 6 Control Systems Analysis and design by the Root-Locus Method 6-1 Introduction 6-2 Root-Locus Plots 6-3 plotting Root Loci with MATLAB 6-4 Root-Locus Plots of Positive Feedback Systems 6-5 Root-Locus Approach to control Systems Design 6-6 Lead Compensation 6-7 Lag Compensation 6-8 Lag-Lead Compensation Example Problems and Solutions Problems Chapter 7 Control Systems Analysis and Design by the Frequency Response Method 7-1 Introduction 7-2 Bode Digrams 7-3 Polar Plots 7-4 Log-Magnitude-versus-Phase plots 7-5 Nyquist Stability Criterion 7-6 Stability Analysis 7-7 Relative Stability Analysis 7-8 Closed-Loop Frequency Response of Unity-feedback Systems 7-9 Experimental Determination of Transfer functions 7-10 Control Systems design by Frequency Response Approach 7-11 Lead Compensation 7-12 Lag Compensation 7-13 Lag-Lead Compensation Example Problems and Solutions Problems Chapter 8 PID Controllers and Modified PID Controllers 8-1 Introduction 8-2 Ziegler- Nichols Rules for tuning PID controllers 8-3 Design of PID Controllers with Frequency Response Approach 8-4 Design of PID Controllers with Computational Optimization Approach 8-5 Modification of PID Control Schemes 8-6 Two-Degrees-of-freedom PID Control Schemes 8-7 Zero Placement Approach to Improve Response Example Problems and Solutions Problems Chapter 9 Control Systems Analysis in State Space 9-1 Introduction 9-2 State-space Representations of Transfer-Function Systems 9-3 Transformation of System Models with MATLAB 9-4 Solving the Time-Invariant State Equation 9-5 Some Useful Results in vector-Matrix Analysis 9-6 Controllability 9-7 Observability Example Problems and Solutions Problems Chapter 10 Control Systems Design of in State Space 10-1 Introduction 10-2 Pole Placement 10-3 Solving Pole-Placement Problems with MATLAB 10-4 Design of Servo Systems 10-5 State Observers 10-6 Design of Regulator Systems with Observers 10-7 Design of Control Systems with Observers 10-8 Quadratic Optimal Regulator Systems 10-9 Robust Control Solutions Example Problems and Solutions Problems Appendix A Appendix B Appendix C References Index
